8-port 10/100/1000Mbps Switch CISCO SG95D-08
8 Port 10/100/1000 Mbps with MDI and MDI crossover (MDI-X); auto negotiated port.
Performance: Switch capacity 16 Gbps, Forwarding capacity(base on 64-byte packets) 11.9 mpps.
Layer 2 Switching: HOL(Head of line) blocking prevention.
QoS: priority levels 4 hardware queues, scheduling priority queuing and weighted round-robin (WRR), class of service 802.1p priority based.
Đặc tính kỹ thuật
| Ports | SG95D-08: 8 RJ-45 connectors for 10BASE-T/100BASE-TX/1000BASE-T ports |
| automatic medium dependent interface (MDI) and MDI crossover (MDI-X); auto-negotiated port for connecting 10-, 100-, 1000-Mbps devices | |
| Standards | IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet |
| Cabling type | Category 5e or better |
| LED indicators | System/PWR, link/activity, 100M, cable diagnostics, loop detection, gigabit, mini-GBIC *if present |
| Power supply | SG95D-08: DC 12V, 1.0A |
| Physical dimensions (W x D x H) | SG95D-08: 160x30x103.5 mm |
| Weight | SG95D-08: 0.94 lb. (0.43 kg |
| Switching capacity | Gbps SG95D-08: 16 Gbps |
| Forwarding capacity | Forwarding rate in million packets per second (mpps) (based on 64-byte packets): SG95D-08: 11.9 mpps |
| Compliance/certifications | UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B |
